Product Details

Aluminium Profile for Extrusion Aluminum Alloy 6000 series with different Sizes

1.The materials we used frequently are also available for 6061 6063 6005 6082 and T4 T5 T6 etc.

2.The surface we used frequently are also available for Mill Finished/Anodizing/ Electrophoresis/ Powder Coating/PVDF/Wooden etc.

3.The size we use frequently are available for FG2020-1.2 /FG2525-1.5/FG30200-1.8/FG10044-2.0 etc.

We have many size tube, please contact Junda. Of course we can open the new moulds according to your requires.

Products information

1，Aluminum extrusion profile (500, 600, 1000, 1450, 1800, 2000, 2200, 2600, 2700, 3600, 4350, 6500, 7500 TONS extrusion machines )

2, Surface treatment for aluminum profile ( Anodizing/ Electrophoresis/ Powder coated/Wooden print/ Sandblasting/ Matte/ Dye/ SHORT anodized & powder coated /Polishing/ brush)

3, Machining for aluminum profile (CNC/punch/ Drill/ tapping/ milling/ bending/ welding/ accurate cutting/ assembly line work etc.)

4, Material No.: 6063, 6061, 6060, 6463, 6005, 6005A, 6082, 3003, 7003. (T3-T8)

5, Application areas

1) Aluminum industry profile (aviation/ farm/ train/auto car/auto truck accessories , heat sink, Military aluminum)

2) Aluminum decoration & building profile (Door & windows curtain wall, roller door & window, ceiling &layering,curtain rail & bracket. furniture profile etc.)

3) Solar accessories & mounting + frame. LEO light system aluminum profile

4)Aluminum Formwork system profile

Details

Name	Metal Aluminum Door and Window Frame Profile With Aluminium Awning Window Accessories
Material	1.We usually do: Alloy 6063,6061; Temper T3-T8 available 2.We can also do many other series, the exact will be in line with your samples or requires
Surface Treatment	Mill Finish, Anodizing, Anodizing Mat, Electrophoresis, Electrophoresis Mat, Powder Coating, PVDF Coating, Wood Grain Painting, Wooden Transfer etc..
Color	Silvery, Champagne, Bronze, Red Copper, Black, White, Red, Green, etc Standard Germany RAL Mark
Thickness	0.8mm-20mm
Open Style	Sliding, Side-Hung, Fixed, Folding-Sliding, Lift-Sliding, Rolling Shutter etc
Length	1.5.85m is best for 20 container 2.5.95m is best for 40 container 3. We can do according the customers' request
Packing	1.Protective Film (with no words or customers' words) on the surface, 5% Composite Papers (with no words or customers' words) wrapped outside 2. Protective Film (with no words or customers' words) on the surface, 5% Craft Papers (with no words or customers' words) wrapped outside 3.Protective Film (with no words or customers' words) on the surface, Shrink Film (with no words or customers' words) outside 4.Others by discussing with customer
Product Standard	1.China National Standard GB5237-2008 2.European Standard EN12020-1,2(2001),EN755.9-1998 3.English Standard EN755-1-2008 4.American Standard ANSI H35.2-2003
MOQ	3tons,120container, 140container
Supply Ability	550,000 tons every year
Port	Qingdao
Delivery time	15-20 days after receiving deposit
Place of Origin	Shandong, China
Payment	T/T 50% deposit and 50% L/C or pay up before loading the container
Certificate	CE,ISO9001,ISO14001,OHSAS18001,BV CERTIFICATE
Moulding	1.Using our moulds, no fees. 2.Using customer drawing, opening new mould under 100% mould charges, then refunding to customer after meeting our standard. 3.Can be negotiated with each other
Quality Promise	50 years no deformation 15 years without colour changing
Aluminum Product	Frame Profile of doors, Thermal-break Aluminum Profile, Curtain wall. Sliding Door, Casement Door, industrial Aluminum Extrusion Profile, Heat Sink, Aluminum Pipe, Aluminium Tube, U Profile,T Profile, etc. Your samples or designs
Services	1.Help customer to open new mould 2.Help customer to design suitable drawings 3.Provide all the accessories for our profile 4.We can make windows with our profile 5.We can buy something for the customers if customer needing 6.We produce made-up windows and doors 7.We provide cutting,melting,bending,drilling,milling,punching,etc other deep processing

NOTE

1. If our Aluminum profiles are not suitable for you, you could provide us your sample or technical drawing, we can extrude according to your designs.

2. If you have your own drawings, please be free to send them to us. Let's talk about the details.

3. We are always trying to provide you our best service and products. Welcome to contact us for the aluminium profile.

Material Performance

Chemical Composition

The Chemical Composition compare between Aluminium Alloy 6063 and 6061as following:

Material	Chemical Composition
Material	Mg	Si	Fe	Cu	Mn	Zn	Cr	Ti	Others	Al
6003	0.45-0.9	0.2-0.6	＜0.35	＜0.1	＜0.1	＜0.1	＜0.1	＜0.1	0.15	The Left
6063A	0.6-0.9	0.3-0.6	0.15-0.35	＜0.1	0.15	0.15	0.05	0.1	0.15	The Left
6061	0.8-1.2	0.4-0.8	0.7	0.15-0.4	0.15	0.25	0.04-0.35	0.15	≤0.15	The Left

Mechanical Property

The Mechanical Property compare between Aluminium Alloy 6063 and 6061as following:

Mechanical Property
Material	Temper	Wall Thickness(mm)	Tensile Test		Hardness
			Tensile Strength(MPa)	Elongation(%)	Sample Thickness(mm)	HW
			Not less Than Below
6063	T5	ALL	160	8	0.8	8
6063	T6	ALL	205	8	-	-
6063A	T5	≤10	200	5	0.8	10
	T5	＞10	190	5	-	-
	T6	≤10	230	5	-	-
	T6	＞10	220	4	-	-
6061	T4	ALL	180	16	-	-
6061	T6	ALL	265	8	-	-

Q: What's your MOQ ?

A: 1 metric ton for each model.

Q: Do the price of all the colors are the same with the same surface treatment?

A: Not yet, For powder coating, the bright-colored will cost higher than white or gray; For Anodizing, colorful will higher than silver, black higher than colorful.

Q: Can you do OEM, how about the mould cost?

A: OEM is welcomed. The mould cost varies from USD160 to USD6000 per set, we will not charge any fee if your order qty is more than 5 tons for normal profiles and 10 tons for curtain wall and industry profiles under normal circumstances.

Q: Does the price of Curtain Wall and Industry aluminum profile the same with windows and doors?

A: The price of Curtain Wall and Industry aluminum profile is a little higher than usual models of window & doors. Because the thickness and structure is different, adding production difficulty and raw material rejection rate.

Q: What are the main market of your products?

A: Our market is global, now mainly focus on Asia, America, Africa and Europe etc..

Q: Which way you calculate the weight?

A: Both theoretical weight and actual weight according to clients requirement.

Q: How can you ensure high quality?

A: 1)we have stable raw material suppliers, the goods have passed very strict inspection.

2)every process will be with high standards and high demand.

3)our QC won't let any defective products get out of our factory.

4)We have so many certificates, ISO9001:2008,ISO14001:2004,ISO10012,etc

Q: How long can you produce?

A: Mill Finish: 13 meters;

Anodizing: 2.5-7.1 meters;

Powder Coating: 2-7.8 meters.

Q: What is your promise about the profile quality?

A: Quality guarantee:

Anodizing: 25 years no colour changing, 50 years no anodized film fall off.

Powder Coating: 10 years no colour changing, 50 years no powder film fall off.

Q:Can you do the deep processing on the profile?

A: Yes, we usually produce windows and doors in quantity, welding, milling,cutting and drilling etc.

Q: Do you provide accessories?

A: We provide all the accessories for you in two ways, we produce and buy. we have one silicon company, we can give you the best price and qualified silicons. we can also provide the machines for making windows.
