Product specifications

Balance of benefits

Sandwich panels with coated metal lining have been used in building industry for over 40 years. Some of the benefits of using our sandwich panels are:

 Thermal insulation.

Thermal conductivity of panels with polyisocyanurate foam core is 0.022 W/mK.

 Durability.

Protection against weather conditions, maintaining properties and appearance for many years. When coating is properly selected for local conditions, several years’ durability of panels may be reached without any problem.

 Waterproofness.

Water, snow and damp will not get through. Perfectly finished joints ensure complete waterproofness for many years, if installation standards are followed.

 Sound absorption.

Properly selected core material can give very good noise insulation parameters. They are particularly important if insulation of outside noise, reduction of industrial noise propagation to the outside of the building or noise reduction within the building is required.

 Fire resistance.

Properties according to the needs. Proper type of core can ensure reaching fire resistance class up to A (mineral wool). This enables protection of escape routes and separation of fire compartments from each other.

 Easy and quick installation, low construction costs.

10mm thick PUR/PIR foam panel has the same heat-transfer coefficient U as a 390 cm thick aerated concrete wall, or a 290 cm thick brick wall.

 Resistance.

Roof panels can withstand the load of snow and wind depending on their thickness and climatic zone, with supports placed every 3 m. Wall panels in most cases can be used with supports span of up to 6 m. This results in real savings in terms of the supporting structure and also in the costs of the entire building.

 Benefits for the natural environment.

Entire power input in the production of the material used for thermal insulation of the building pays for itself after two or three years from installation, on average. Materials used in production are recyclable. Steel can be easily reused. Waste core materials can also be recycled, while production of the panels itself is not harmful to the environment.

FAQ

1. How to control the quality of your product?

a) Quality of the design: think about possible problems in advance and provide a high quality design solution.

b) Quality of the raw material: choose the qualified raw material

c) Quality of the production: precise manufacturing technique, experienced workers, strict quality inspection.

2.How about your lead time?

It will take 3-7 days for budget and design according to the drawings after receiving the

deposit. 20-40 days if there are some special sizes.

3. How can we guarantee quality?

Always a pre-production sample before mass production;

Always final Inspection before shipment;

4.What can you buy from us?

sandwich panels,PUR sandwich panels,PIR Sandwich panel,cold storage sandwich panels,rock wool sandwich panels

5. How long is your warranty? What kind of after-sale service can you provide?

Our warranty is 1 years since the project done.

During the warranty time, if anything has problems, we will replace it.

If you can’t handle it, we will send engineer come to solve it without any charge.
